· 15", 1024 x 768 Open Frame Display
· VGA and HDMI input
· PCAP Touch
· Open frame
· 15", 1024 x 768 Open Frame Display
· VGA and HDMI input
· PCAP Touch
· Open frame
Open frame displays with 15-inch screen size and a 1024 x 768 resolution offer a crisp and clear display for various industrial and commercial applications. The high-resolution screen ensures detailed visuals and enhances the viewing experience, making it suitable for applications that require precise data visualization or image clarity. With its compact size, the Open frame Display can be easily integrated into space-constrained environments without compromising on visual quality. Whether used for monitoring systems, control panels, or information displays, the Open frame Display with its 15-inch screen and high resolution delivers a reliable and visually appealing display solution.
Specification:
| 15" Open Frame TOUCH Monitor | |
| Mode Name | LC-OF1501T-CA |
| Screen Size | 15" |
| Active Display Area (mm) | 304.128mm(W)×228.096mm(H) |
| Display Mode | 4:3 |
| LCD Type | TFT-LCD |
| Resolution | 1024×768 |
| Display Color | 16.7M |
| Pixel Pitch(mm) | 0.297(H)×0.297(V) |
| Brightness(nits) | 350cd/㎡ |
| Contrast Ratio | 700:1 |
| Viewing Angle | 140(H) /125(V) |
| Response Time | 4ms |
| Backlight | LED |
| Interface | VGA,DVI |
| Optional interface | HDMI,BNC |
| Power | DC12V 3A 50HZ/ 60HZ/ 75HZ |
| Power Consumption | ≦20W |
| Plug & Play | DDC 1/2B |
| OSD Control | Auto adjust, Brightness, Contrast, Hori. / Vert. Position, Clock, phase, Color, Language.. |
| Menu | Chinese/English(other languages supported) |
| TOUCH | |
| Standard touch opetions | resistive 5 wire, projected capacitive touch |
| Customized touch options | IR touch / SAW touch |
| Mount Way | |
| Mounting | VESA 75mm/100mm,flanges at side option |
| Certificate Approval | CE,RoHS,CCC,FCC,ISO9000(optional UL) |
| Warranty | 1.5 years |
| Application | |
| ATM/ Kiosk/Transportation/ Industrial Automation/Medical Treatment | |
Our products have got CE, RoHS, FCC, CCC certificates. We also carry out a strict quality management system in accordance with ISO9001 requirements.
Anrecson is a leading manufacturer, specializing in designing&producing LCD products, including touchscreen monitor, open frame monitor, industrial monitor, panel pc, digital signage, CCTV monitor and video wall, 4K Monitor, AHD/CVI/TVI/CVBS 4 in 1 monitor etc. The size ranges from 5 inch to 128 inch.
We own 15 engineers’ R&D department, which can meet your all kinds of customization requirement. We provide fast response and best solution according to each project. And professional equipment includes Pulse wave, shaking, static electricity, and temperature and humidity testing....
Anrecson Brand Monitors are widely used in traffic control center, broadcasting system, military, city square, shopping mall, bank,school and hospital,etc. Devices like ATM, Self-service kiosk, Transportation, Automatic Vending Machine, Gaming Machine, Pos, Medical Treatment, CNC Machine also use our Anrecson monitor.
Our products have got CE, RoHS, FCC, CCC certificates. We also carry out a strict quality management system in accordance with ISO9001 requirements.
High-end technology Good quality Reasonable price Fast delivery Excellent customer service
Shenzhen Anrecson Electronics Co.,Ltd
ADD:7/F, Building4, Yu Sheng Industrial Park, Xixiang Street, Bao'an District, Shenzhen, 518126, China
TEL:+8613502838424
